#include <simpleserver.h>
Public Member Functions
- SimpleServer (unsigned short port)
Protected Member Functions
- virtual int read_from_client (int filedes)
- virtual void executeCmd (int client, short cmd, unsigned int *arg, short n)
- virtual void executeCmd (int client, short cmd, unsigned long *arg, short n)
Detailed Description
Implements a simple IP server.
The server waits for connections. The communication with the client is defined in the protected function read_from_client. Overload this function for a specific application.
The SimpleServer automatically detects the byte order of the client process and transfers all data in client byte order.
- Todo:
Use a independant threads for all connections. If one connection hangs, the other won't be affected?!
Improve the Server managment. Loging, Shutdown via IP. For some other purpose a New class similar to Pbus/PbusProxy couble may be useful for mainanace and run control. Eg. Shutdown + restart of the Server, Control of the IRdispatcher!!!
Changes:
- 30.8.05 ak: Detect client byte order
- 4.11.02 ak: Add stdin to the select functions. The server is now responding to socket and keyboard input! Improved output of the server - format similar to that of netstat --ip.
- 31.10.02 ak: Closing all connected sockets before shutdown. This prevents hanging connections after terminating the server.
- 18.3.01 ak: Protected variable for the output stream introduced - stop this nasty messages in the terminal!!!
Definition at line 61 of file simpleserver.h.
Constructor & Destructor Documentation
| SimpleServer::SimpleServer | ( | unsigned short | port | ) |
Member Function Documentation
| virtual void SimpleServer::executeCmd | ( | int | client, |
| short | cmd, | ||
| unsigned int * | arg, | ||
| short | n | ||
| ) | [protected, virtual] |
Execute a command - The instruction set on the client side remoteCall needs to fit to this implementation.
Reimplemented in GpsServer, and TsBackgroundLoop.
| virtual void SimpleServer::executeCmd | ( | int | client, |
| short | cmd, | ||
| unsigned long * | arg, | ||
| short | n | ||
| ) | [protected, virtual] |
Reimplemented in TsBackgroundLoop, and EventLoop.
| virtual int SimpleServer::read_from_client | ( | int | filedes | ) | [protected, virtual] |
Defines the interface from the communication with the proxy process.
The function is able to detect if the client uses a different byte order and automatically re-orders the data. All following communication will be swapped to have the appropriate byte order.
The protocol is defined as follows:
- command (4 bytes)
- len (4 bytes)
- data (len * 4bytes)
Reimplemented from BaseServer.
Reimplemented in GpsServer, and EventLoopClient.
The documentation for this class was generated from the following file:
- /home/kopmann/git-mirror/fdhwlib/fdhwlib/akutil/simpleserver.h
